varioPROP

for model airplanes from
8 kg to 25 kg g weight
shaft diameter
to 14,0 mm
adjustable upward gradient from
6,0'' (152,4 mm) to ca. 35'' (889 mm)
propeller diameter from
18,8'' (478 mm) to 25,8'' (655 mm)

for model airplanes from
14 kg to 40 kg g weight
shaft diameter from
to 14,0 mm
adjustable upward gradient from
8,0'' (203 mm) to ca. 38'' (956 mm)
propeller diameter from
26,6'' (676 mm) to 31,3'' (795 mm)

for model airplanes from
ca. 2.800 to 15.000 g weight
shaft diameter from
6,0 mm to 12,0 mm
adjustable upward gradient from
6,0'' (152,4 mm) to ca. 25'' (635 mm)
propeller diameter from
16,2'' (412 mm) to 22,6'' (574 mm)

Into each hub of size 6A, 8B or 12C folding joints from high-strength aluminium can be installed instead of the propeller blades. So - with a hub you maybe already have - you can build hinged propellers with 2 to even 5 blades.

Spinners are available as accessories to the individual hub sizes (6A, 8B, 12C and 16D).

Propeller blades, which can be used with electric or gas engines. Due to the drive oscillations of a gas engine only special propeller blades may be used up to a reduced speed limit.

Left handed blades
are running anticlockwise,
when looking
in flight direction.

for model airplanes from
ca. 1.000 to 5.000 g weight
shaft diameter from
4,0 mm to 8,0 mm
adjustable upward gradient from
4,0'' (102 mm) to ca. 15'' (381 mm)
propeller diameter from
10,1'' (256 mm) to 15,2'' (386 mm)

for model airplanes from
ca. 500 to 2.500 g weight
shaft diameter from
3,0 mm to 6,0 mm
adjustabele upward gradient from
3,0'' (76 mm) to ca. 10'' (254 mm)
propeller diameter from
7,9'' (200 mm) to 12,4'' (315 mm)

for model airplanes from
ca. 100 to 1.000 g weight
shaft diameter from
2,3 mm to 4,0 mm
adjustable upward gradient from
2,5'' (64 mm) to ca. 6'' (152 mm)
propeller diameter from
5,1'' (129 mm) to 9,6'' (243 mm)
